Paneling That Keeps the Grain and Drops the Timber Risk
Wood veneer paneling in the Eastopo range is not sliced timber on a board. The wood grain you see is a decorative PVC film, laminated onto a hollow core PVC panel and sealed under a UV-cured topcoat. The result carries the oak, walnut or ash reading of real veneer paneling without the jobsite lottery - no cupping, no grain mismatch between sheets, no sanding schedule, no risk of a damp wall delaminating the face. It is paneling a contractor can price, order and fit to a programme.
For a buying decision the useful way to read "wood veneer paneling" is as a look, not a material claim. The look is warm timber; the build is engineered PVC. Because the core is PVC, every sheet in a batch matches by shade number, the water absorption test sits at ≤ 0.5% (EN 13245-2 Section 5.4), and the wall wipes clean with a damp cloth. Because the core is hollow, the panel stays light enough for one fitter to handle on site. That combination - timber aesthetics, engineered behaviour, contractor-friendly weight - is the reason this range keeps winning corridor, shower room and hospitality walls.
Two things separate Eastopo paneling from low-cost lookalikes. The film is laminated, not printed and coated, so the grain does not wear through at edges or traffic lines. And the hollow core uses parallel rectangular channels with solid PVC skins, which keeps the sheet rigid across the full width while holding screw fixings in the skin. Cheap foam-core boards flex, telegraph the substrate and spit fixings; this build does not. The specification table further down puts numbers on both.
Panel Formats, Coverage and the Joint Count
The wall panel range runs in two widths, and the width decision is a visual one as much as a cost one. A 600 mm panel gives a tighter plank rhythm - the classic timber cladding look with a joint every 600 mm. A 1000 mm panel is the wide-format board: a 2-metre wall plane takes just two panels and one mechanical joint, which is the choice when the design wants an almost seamless timber plane. Thickness is 8 mm for standard walls and ceilings-height work, or 10 mm where the wall takes carts, chairs or corridor traffic.
The arithmetic that matters on a tender: a 600 mm x 2400 mm panel covers 1.44 m²; a 1000 mm x 2400 mm panel covers 2.40 m². Ordering 60 m² of wall in 600 mm boards means about 42 panels, and with a 5% cutting allowance the practical order is 44. In 1000 mm boards the same wall takes 25 panels and the practical order is 27. The same mathematics holds for ceiling panels, which follow the PVC ceiling panel width programme from 100 to 600 mm - detailed in the specification section below.
Lengths are 2400 mm as standard and cut to order, so full-height commercial storeys and 3-metre walls order exactly what they need instead of stacking horizontal joints. Every panel carries a full-length tongue and groove on both edges, which locks the sheets together and hides the fixing line.
What You Are Actually Cladding With
Peel one end cap off a sheet and the build is visible: two solid PVC skins enclosing parallel rectangular hollow channels that run the full length of the panel. The skins carry the finish and take the fixing; the channels take the weight out of the sheet. Weight sits at 3.5–4.5 kg/m² depending on thickness - roughly a third of what a comparable boarded system weighs on the wall, which is why Eastopo paneling moves fast on refurbishment programmes where access is tight.
The face is made in two passes. A decorative wood-grain PVC film is laminated to the panel skin during production, then a UV-cured topcoat is applied at 2H pencil hardness or better. The film carries the continuous grain; the topcoat carries the scratch, stain and cleaning resistance. Because the face is a sealed, non-porous surface, grease, marker pen and cleaning chemicals wipe off without solvent and without leaving ghost marks - the difference between a wall that cleans and a wall that needs refinishing.
The compound is stabilised with calcium-zinc, lead-free and cadmium-free, and the decorative films are E0-class, so rooms can be occupied as soon as the panels are up and the tape is off. There is no wood substrate anywhere in the build, which is precisely why the panel does not swell, rot, feed mould or change dimension with the seasons.
Fitting the Panels: Tongue and Groove Sequence
The T&G profile is what makes this a two-person system rather than a joinery job. Panels engage along the full length of the board and lock mechanically, so the seam stays flat without clamping pressure while the adhesive cures. The sequence on a typical commercial wall:
1. Check the substrate. The wall must be reasonably flat and dry; plasterboard, plywood and existing smooth render all work. Mark the stud or batten positions if screw fixing is planned.
2. Plumb the first panel. Set the first sheet dead vertical with a spirit level; every joint error downstream inherits from this panel. Fix it through the tongue edge so the fixing is hidden by the next sheet.
3. Apply adhesive and engage. Run structural adhesive in vertical dabs down the back of each new panel, offer it to the groove of the previous sheet and tap the tongue home with a rubber block, working from one end to the other.
4. Cut clean and support ends. Score-and-snap or use a fine-tooth blade for the cuts; PVC cuts fast and clean. Support panel ends at openings and corners with the same adhesive or batten detail as the field.
5. Trim and wipe. Complete the room with the matching edge and corner profiles, wipe the faces with a damp cloth to lift dust, and hand the wall over. No sanding, no sealing, no curing schedule beyond the adhesive manufacturer's.
Ceiling panels fix the same way through the tongue into the ceiling structure; for suspended grid layouts the panels sit in the grid and the T&G holds the plane flat. Confirm the ceiling fixing detail with the export team before ordering, and the batch certificate travels with the shipment either way.
Estimating a Wall or Ceiling Job
The buying question is almost always the same: how many square metres, and what do they cost per square metre delivered. The square metre count is the honest unit - Eastopo quotes per square metre, not per panel, so a 600 mm and a 1000 mm width compare directly on price.
To estimate: measure the wall or ceiling area in square metres, add 5% for cutting and openings, then divide by the panel coverage. A 60 m² corridor at 600 mm width takes about 44 panels (62 m² including allowance, 1.44 m² per panel). The same corridor at 1000 mm width takes 27 panels (2.40 m² each). Doors and openings come out of the allowance; cut-offs from openings usually cover the small returns around frames.
Full-height walls order lengths to suit the storey height instead of stacking joints - 2700 mm or 3000 mm heights cut from the custom length programme. For a mixed project - corridors in 1000 mm boards, a ceiling in the 400 mm ceiling panel width - the export team prices the two lines on one order, and the MOQ structure below is designed exactly for that mix.
Specification Sheet
The table below is the specification Eastopo quotes for the hollow core wall paneling range. Ceiling panels share the same build and run on the PVC ceiling panel width programme, summarised beneath the table.
| Parameter | Value | Note |
|---|---|---|
| Product | Wood-grain hollow core PVC wall paneling | Wood veneer effect, not real timber |
| Panel widths | 600 mm / 1000 mm | Plank rhythm or wide format |
| Lengths | 2400 mm standard; custom lengths on request | Cut to order |
| Thickness | 8 mm / 10 mm | 10 mm for traffic walls |
| Coverage per panel | 1.44 m² (600 x 2400 mm); 2.40 m² (1000 x 2400 mm) | Use for estimating |
| Weight | 3.5 – 4.5 kg/m² by thickness | One fitter friendly |
| Core | Hollow core PVC, parallel rectangular channels | Rigid, screw-holding skins |
| Face | Wood-grain PVC film + UV-cured topcoat ≥ 2H | Sealed, wipe-clean surface |
| Joint | Full-length tongue and groove | Mechanical lock, hidden fixings |
| Water absorption | ≤ 0.5% (EN 13245-2 §5.4) | Wet area safe |
| Fire classification | EN 13501-1 Class B-s2,d0 | Certificate on request |
| Certification | CE EN 13245-2:2008 | Cert no. SC-PSC-4-2026-06-54 |
| MOQ | 500 m² per colour and finish | Mixed widths on one order |
| Lead time | 18 – 22 days stock; 28 – 35 days custom | From order confirmation |
| Use | Interior walls | Indoor only |
Ceiling panels: same hollow core build and wood-grain faces, widths 100 / 150 / 200 / 250 / 300 / 400 / 600 mm on the PVC ceiling panel programme, thickness 5–8 mm, weight 1.6–3.0 kg/m² by thickness, 2400 mm standard length with custom lengths on request. Tongue and groove joint, fixed through the tongue into the ceiling structure or into a suspended grid.
Wet Rooms, Corridors and Reception Walls
The specification earns its keep in the rooms where real veneer paneling has no business. Shower rooms and kitchens put steam, splash and cleaning chemicals on the wall; the sealed PVC face and the ≤ 0.5% water absorption test (EN 13245-2 Section 5.4) remove the moisture conversation entirely. Seal the joints and cut edges with the matching trim in wet zones, keep the cavity behind the panel dry, and the wall is a permanent, non-porous surface.
Corridors and hospitality walls get trolleys, luggage and marker pens. The 10 mm panel takes the impact through the skin, and marks wipe off the UV topcoat without ghosting - the maintenance difference between a panel that wipes and a veneer that refinishes. Reception and lobby walls get the grain. Oak, walnut, teak and grey-oak reads run by shade number, and a 1000 mm panel keeps the joints out of sight on the planes guests photograph.
None of this claims PVC paneling replaces timber everywhere - genuine wood veneer has its projects. It claims the rooms above are where the engineered panel is the lower-risk specification, and that is the conversation Eastopo wants buyers to have before they compare prices.
Ordering, Samples and Lead Times
Eastopo runs the wood veneer paneling range out of its Haining facility, where 36 extrusion lines cover PVC wall and ceiling panels with a combined monthly capacity of 600,000–800,000 m². MOQ is 500 m² per colour and finish, mixable across the 600 mm and 1000 mm widths and the ceiling panel programme on a single order. Stock finishes leave in 18–22 days; custom films, matched shades and private-label packaging run 28–35 days from confirmation.
Sample cards and cut samples ship within a few days so a specification can be frozen before production - grain, shade and thickness approved on the sample that becomes the batch reference. Incoterms offered are EXW, FOB, CFR or CIF. Send the wall and ceiling areas, preferred width and grain to the export team and the quote returns with a lead time and loading plan.
FAQ
Is this real timber veneer paneling? +
No. The wood grain is a decorative PVC film, laminated to a hollow core PVC panel and sealed under a UV-cured topcoat. There is no timber slice and no wood substrate. The point of the build is that it reads like oak or walnut veneer while staying waterproof, matchable by shade number and maintenance-free - the properties real veneer cannot offer on commercial walls.
Should I choose the 600 mm or the 1000 mm panel? +
It is a visual decision. 600 mm panels give the classic timber plank rhythm with a joint every 600 mm; 1000 mm panels are the wide format that reads as a nearly seamless plane, with a 2-metre wall taking just two panels. Thickness follows traffic: 8 mm for standard walls, 10 mm for corridors and public areas. Both widths are hollow core, both carry the same grain options.
Can one fitter install these panels? +
Yes. Panels weigh 3.5–4.5 kg/m² by thickness, so a single fitter handles and cuts a sheet, and the full-length tongue and groove locks each panel home without clamping. A two-person crew is faster on long runs, but the system is genuinely one-person friendly on refurbishment jobs with tight access.
Are these panels suitable for bathroom and kitchen walls? +
Yes for normal wall use. Water absorption is ≤ 0.5% tested to EN 13245-2 Section 5.4, and the sealed face rejects steam, splash and cleaning chemicals. In showers and wet zones, seal the joints and cut edges with the matching trim and keep the cavity behind the panel dry. The panel is waterproof; the wall structure is a separate responsibility.
How do I estimate how many panels I need? +
Measure the wall area in square metres, add 5% for cutting, and divide by panel coverage: 1.44 m² per 600 x 2400 mm panel, 2.40 m² per 1000 x 2400 mm panel. A 60 m² corridor in 600 mm boards needs about 44 panels including allowance. The export team rechecks the arithmetic on the quote.
What happens to the joint when the panel expands? +
PVC has a low coefficient of thermal expansion and there is no wood core to move with humidity, so the panel does not swell or cup with the seasons. The tongue-and-groove joint locks mechanically and the recommended adhesive bed allows the small thermal movement a PVC wall panel has, without gaps opening at the seams.
Can the panels go on ceilings as well as walls? +
Yes. Dedicated ceiling panels run on the PVC ceiling panel width programme - 100 to 600 mm in 5 to 8 mm thickness - with the same wood-grain faces, fixed through the tongue into the ceiling structure or into a suspended grid. They weigh 1.6–3.0 kg/m² by thickness, so the grid load stays low.
What is the minimum order and how long does delivery take? +
MOQ is 500 m² per colour and finish, mixable across widths and the ceiling programme on one order. Stock finishes ship in 18–22 days from confirmation; custom films and private-label packaging run 28–35 days. Samples leave within a few days so the specification can be frozen before production. Incoterms: EXW, FOB, CFR or CIF.
About the Author
Written by J. Mao - Eastopo New Materials
J. Mao is the Export Manager at Hangzhou Eastopo New Materials Technology Co., Ltd., and works on hollow core PVC wall and ceiling panel exports to the UK, EU, US, Australia and New Zealand, including wood-grain film lamination finishes and the installation practice behind them.
Questions on this page? Email mj@eastopo.com or WhatsApp +86 193 5725 8106.
Send your wall and ceiling areas, preferred width (600 mm or 1000 mm), grain finish and quantity for a factory quote under EXW, FOB, CFR or CIF - the export team replies within one working day.
